M24C64-W Description
1 Description The M24C64 is a 64-Kbit I2C-patible EEPROM (electrically erasable programmable memory) organized as 8K × 8 bits. The M24C64-D offers an additional page, named the identification page (32 byte). The identification page can be used to store sensitive application parameters which can be (later) permanently locked in read-only mode.
M24C64-W Key Features
- patible with following I2C bus modes
- 400 kHz
- 100 kHz
- Memory array
- 64 Kbit (8 Kbyte) of EEPROM
- Page size: 32 byte
- Additional Write lockable page (M24C64-D order codes)
- Single supply voltage
- 1.7 V to 5.5 V over -40 °C / +85 °C
- 1.6 V to 5.5 V over 0 °C / +85 °C
