STMicroelectronics STA311B
This is information on a product in full production.| Part No. | STA311B |
|---|---|
| Datasheet | STA311B Download |
| Manufacturer |  STMicroelectronics |
| Description | Multichannel digital audio processor |
| Buy | Stock & Price |
FEATURES
● 8 channels of 24-bit FFX™● >100 dB SNR and dynamic range
● Selectable 32 kHz-192 kHz input sampling rates
● 6 channels of DSD/SACD
● Digital gain/attenuation +58 dB to -100 dB in 0.5 dB steps
● Advanced “pop-free” operation
● Digital “pop-free” operation for single-ended mode
● Soft volume update
● Individual channel and master gain/attenuation plus channel trim (-10 dB to +10 dB)
● Up to 10 independent 32-bit user- programmable biquads (EQ) per channel
● Bass/treble tone control
● Pre- and post-EQ full 8-channel input mix on all 8 channels
● Dual independent limiters/compressors
● Dynamic range compression or anti-clipping modes
● AutoModes – 5-band graphic EQ Datasheet - production data – 32 preset EQ curves (rock, jazz, pop, etc.) – Automatic volume-controlled loudness – 5.1 to 2-channel downmix – Simultaneous 5.1- and 2-channel downmix outputs – 3 preset volume curves – 2 preset anti-clipping modes – Preset movie nighttime listening mode – Preset TV channel/commercial A...
