STMicroelectronics STM32F030F4
the STM32F030x4/x6/x8/xC microcontrollers. This document should be read in conjunction with the STM32F0x0xx reference manual (RM0360). The reference manual is available from the STMicroelectronics website For information on the Arm®(a) Cortex®-M0 core, please refer to the Cortex®-M0 Technical Reference Manual, available from the website.| Part No. | STM32F030F4 |
|---|---|
| Datasheet | STM32F030F4 Download |
| Manufacturer |  STMicroelectronics |
| Description | 32-bit MCU |
| Buy | Stock & Price |
FEATURES
● Core: Arm® 32-bit Cortex®-M0 CPU, frequency up to 48 MHz● Memories – 16 to 256 Kbytes of Flash memory – 4 to 32 Kbytes of SRAM with HW parity
● CRC calculation unit
● Reset and power management – Digital & I/Os supply: VDD = 2.4 V to 3.6 V – Analog supply: VDDA = VDD to 3.6 V – Power-on/Power down reset (POR/PDR) – Low power modes: Sleep, Stop, Standby
● Clock management – 4 to 32 MHz crystal oscillator – 32 kHz oscillator for RTC with calibration – Internal 8 MHz RC with x6 PLL option – Internal 40 kHz RC oscillator
● Up to 55 fast I/Os – All mappable on external interrupt vectors – Up to 55 I/Os with 5V tolerant capability
● 5-channel DMA controller
● One 12-bit, 1.0 µs ADC (up to 16 channels) – Conversion range: 0 to 3.6 V – Separate analog supply: 2.4 V to 3.6 V
● Calendar RTC with alarm and periodic wakeup from Stop/Standby
● 11 timers – One 16-bit advanced-control timer for six-channel PWM output – Up to seven 16-bit timers, with up to four IC/OC, OCN, usable for IR c...
