STM32MP157D Datasheet Arm Dual Cortex-a7 650 Mhz + Cortex-m4 Mpu

Manufacturer: STMicroelectronics

Overview: STM32MP157A/D Arm® dual Cortex®-A7 800 MHz + Cortex®-M4 MPU, 3D GPU, TFT/DSI, 37 m. interfaces, 29 timers, adv.

This datasheet includes multiple variants, all published together in a single manufacturer document.

Key Features

  • Includes ST state-of-the-art patented technology Core.
  • 32-bit dual-core Arm® Cortex®-A7.
  • L1 32-Kbyte I / 32-Kbyte D for each core.
  • 256-Kbyte unified level 2 cache.
  • Arm® NEON™ and Arm® TrustZone®.
  • 32-bit Arm® Cortex®-M4 with FPU/MPU.
  • Up to 209 MHz (Up to 703 CoreMark®) Memories.
  • External DDR memory up to 1 Gbyte.
  • up to LPDDR2/LPDDR3-1066 16/32-bit.
  • up to DDR3/DDR3L-1066 16/32-bit.
  • 708 Kbytes of internal SRAM.
