STM32WLE5xx STM32WLE4xx Multiprotocol LPWAN 32-bit Arm® Cortex®-M4 MCUs, Lo Ra®, (G)FSK, (G)MSK, BPSK, up to 256KB flash, 64KB SRAM - production data Features Includes ST state-of-the-art patented technology Radio - Frequency range: 150 MHz to 960 MHz - Modulation: Lo Ra®, (G)FSK, (G)MSK and BPSK - RX sensitivity: - 123 d Bm for 2-FSK (at 1.2 Kbit/s), - 148 d Bm for Lo Ra® (at 10.4 k Hz, spreading factor 12) - Transmitter high output power, programmable up to +22 d Bm - Transmitter low output power, programmable up to +15 d Bm - Available integrated passive device (IPD) panion chips for optimized matching, filtering and balun, all in one very pact solution covering each package and each main use cases (22 d Bm @ 915 MHz, 14 d Bm @ 868 MHz, 17 d Bm @ 490 MHz) - pliant with the following radio frequency regulations such as ETSI EN 300 220, EN 300 113, EN 301 166, FCC CFR 47 Part 15, 24, 90, and the Japanese ARIB STD-T30, T-67, T-108 - patible with standardized or proprietary protocols such as Lo Ra WAN®, Sigfox™, W-MBus and more (fully open wireless system-on-chip) Ultra-low-power platform - 1.8 V to 3.6 V power supply - - 40 °C to +105 °C temperature range - Shutdown mode: 31 n A (VDD = 3 V) - Standby (+ RTC) mode: 360 n A (VDD = 3 V) - Stop2 (+ RTC) mode: 1.07 µA (VDD = 3 V) UFQFPN48 (7 x 7 mm) UFBGA73 (5 x 5 mm) - Active-mode MCU: < 72 µA/MHz (Core Mark®) - Active-mode RX: 4.82 m A - Active-mode TX: 15 m A at 10 d Bm and 87 m A at 20 d Bm (Lo Ra® 125 k...
