TL074 - Low-noise JFET quad operational amplifier

Product Overview

STMicroelectronics

Datasheet Details

Part number	TL074
Manufacturer	STMicroelectronics
File Size	564.93 KB
Description	Low-noise JFET quad operational amplifier
Datasheet	TL074 Datasheet
Note	This datasheet PDF includes multiple part numbers: TL074, TL084. Please refer to the document for exact specifications by model.
Additional preview pages of the TL074 datasheet.

Product details

Description

The TL084, TL084A, and TL084B are high-speed, JFET input, quad operational amplifiers incorporating well matched, high voltage JFET and bipolar transistors in a monolithic integrated circuit.

Features

Wide common-mode (up to VCC+) and differential voltage range.
Low input bias and offset current.
Output short-circuit protection.
High input impedance JFET input stage.
Internal frequency compensation.
Latch up free operation.
High slew rate: 16 V/s (typical) P TSSOP14 (Thin shrink small outline package).
