TL432 - Automotive adjustable voltage reference

Product Overview

STMicroelectronics

Part number	TL432
Manufacturer	STMicroelectronics
File Size	772.73 KB
Description	Automotive adjustable voltage reference
Datasheet	TL432 Datasheet
Note	This datasheet PDF includes multiple part numbers: TL432, TL431. Please refer to the document for exact specifications by model.
Additional preview pages of the TL432 datasheet.

The TL431 and TL432 are adjustable shunt voltage references with guaranteed temperature stability over the entire operating temperature range.

The device temperature range is extended for the automotive version from -40 °C up to +125 °C.

AEC-Q100 qualified.
Adjustable output voltage: 2.5 to 36 V.
Sink current capability: 1 to 100 mA.
Typical output impedance: 0.22 Ω.
0.5% voltage precision only on the TL431B version.
1% and 2% voltage precision.
Automotive temp. range -40 °C to +125 °C September 2022 This is information on a product in full production. DocID4467 Rev 17 1/22 www. st. com Contents Contents TL431, TL432 1 Schematic diagrams.
