SGK1314-50A Overview
The SGK1314-50A is a high power GaN-HEMT that is internally matched for standard munication bands to provide optimum power and gain in a 50ohm system. Gain pression Point, S.C.L. Single Carrier Level CASE STYLE RoHS pliance ESD IBK YES Class 1C 1000V to 2000V Note.
SGK1314-50A Key Features
- High Output Power: Pout=47.0dBm (Typ.)
- High Gain: GL=8.0dB (Typ.)
- High P.A.E.: add=29% (Typ.)
- Broad Band: 13.75 to 14.5GHz
- Impedance Matched Zin/Zout = 50ohm
- Hermetically Sealed Package DESCRIPTION The SGK1314-50A is a high power GaN-HEMT that is
