SC2569 - High Performance Current Mode PWM Controller

Download the SC2569 datasheet PDF. This datasheet also covers the SC2569-Safety variant, as both devices belong to the same high performance current mode pwm controller family and are provided as variant models within a single manufacturer datasheet.

General Description

SC2569 combines a highly integrated current mode PWM control IC optimized for high performance, low standby power and cost effective off line flyback converter applications.

PWM switching frequency at normal operation is externally programmable and trimmed to tight range.

Key Features

  • Extended Burst Mode Control For Improved Efficiency and Minimum Standby Power Design.
  • Power-on Soft Start Reducing MOS Stress.
  • Audio Noise Free Operation.
  • External Programmable PWM Switching Frequency.
  • Low VDD startup and operating current.
  • Frequency jitter to Minimize EMI.
  • Leading edge blanking on current sense.
  • Internal Synchronized Slope Compensation.
  • Low VIN/VDD Startup Current(6.5uA) and Low Operating Current(2.0mA).
  • Complete Protection Cov.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (SC2569-Safety-Chip.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number SC2569
Manufacturer Safety-Chip
File Size 518.93 KB
Description High Performance Current Mode PWM Controller
Datasheet download datasheet SC2569 Datasheet
