PK160FG120
PK160FG120 is THYRISTOR / DIODE manufactured by SanRex Corporation.
- Part of the PK160FG40 comparator family.
- Part of the PK160FG40 comparator family.
Features
- Glass-passivated junctions Features
- High Surge Current
- Low loss (VTM=1.5V)
PK series
Typical Applications
- Motor Controls
- Temperature Controls
- Lighting Controls
PD series
< Maximum Ratings >
Symbol
Item
VRRM VRSM VDRM I T(AV) I T(RMS)
Repetitive Peak Reverse Voltage Non-Repetitive Peak Reverse Voltage Repetitive Peak Off-state Voltage Average On-state Current R.M.S. On-state Current
I TSM I2t PGM PG(AV) I FGM VFG M VRG M di/dt V ISO Tj T stg
Surge On-state Current
I 2 t (for fusing)
Peak Gate Power Dissipation
Average Gate Power Dissipation
Peak Gate Current
Peak Gate Voltage (Forward)
Peak Gate Voltage (Reverse)
Critical Rate of Rise of On-state Current
Isolation Breakdown Voltage
Operating Junction Temperature
Storage Temperature
Mounting Torque
Mounting M6 Terminals M6
Mass
PK160FG40 400
(Tj = 25°C unless otherwise noted)
Ratings PK160FG80 PK160FG120 PK160FG160
Unit
T C = 84°C
T C = 84°C 1/2 cycle, 50Hz/60Hz, Peak value, Non-repetitive Value for one cycle surge current
5000/5400...
