Sanken CTXA-4202S
The CTXA-4202S is a fast recovery diode which TO3P-3L realize a peak reverse voltage of 200 V, a typical (4) forward voltage drop of 0.90 V and typical trr of 18 ns K optimizing a life-time control. It has the characteristics suit for PFC circuit of CCM. The low thermal resistance package achieves high performance in terms of heat dissipation.| Part No. | CTXA-4202S |
|---|---|
| Datasheet | CTXA-4202S Download |
| Manufacturer |  Sanken |
| Description | Fast Recovery and High Power Diode |
| Buy | Stock & Price |
FEATURES
Package● VRM------------------------------------------------------ 200 V
● VF------------------------------------ 1.2 V max. (IF = 10 A)
● IF(AV)------------------------------------------------------- 20 A
● trr---------------------------------------------------- 25ns max. (IF = 500 mA, IRP = 500 mA, 90 % of R.P.) igns (1) (2) (3) Des A K A Not to scale
APPLICATIONS
w● For PFC Circuit (CCM) e
● For White Goods
● For Telecommunication Device, etc. or N
ABSOLUTE MAXIMUM RATINGS
f● Unless otherwise specified, TA is 25 °C d Parameter e Peak Repetitive Reverse Voltage d Average Forward Current en Surge Forward Current m I2t Limiting Value m Junction Temperature o Storage Temperature Symbol VRM IF(AV) IFSM I2t Tj Tstg Rating Unit 200 V 20 A 100 A 50 A2s −40 to 150 °C −40 to 150 °C Rec
ELECTRICAL CHARACTERISTICS
t● Unless otherwise specified, TA is 25 °C No Parameter Symbol Test Conditions Min. Notes 10 ms Half sinewave, one shot 1 ms ≤ t ≤10 ms Typ. Max. Unit Forward Voltage Dro...
