Sanken CTXS-6603S
The CTXS-6603S is a high power and fast recovery TO247-3L diode which realize a peak reverse voltage of 300 V, a (4) typical forward voltage drop of 1.05 V and typical K trr-time of 32 ns optimizing a life-time control. It has the characteristics suit for PFC circuit of CCM. The low thermal resistance package achieves high performance in terms of heat dissipation.| Part No. | CTXS-6603S |
|---|---|
| Datasheet | CTXS-6603S Download |
| Manufacturer |  Sanken |
| Description | Fast Recovery and High Power Diode |
| Buy | Stock & Price |
FEATURES
Package● VRM------------------------------------------------------ 300 V
● VF------------------------------------ 1.4 V max. (IF = 30 A) s
● IF(AV)------------------------------------------------------- 60 A n
● trr----------------------------------------------------50 ns max. ig (IF = 500 mA, IRP = 500 mA, 90 % of R.P.) (1) (2) (3) AKA Des
APPLICATIONS
w● For PFC Circuit (CCM) e
● For Large Current Secondary Side Rectifier
● For DC-DC converter, etc. Not to scale or N
ABSOLUTE MAXIMUM RATINGS
f● Unless otherwise specified, TA is 25 °C d Parameter e Peak Repetitive Reverse Voltage d Average Forward Current en Surge Forward Current m I2t Limiting Value m Junction Temperature o Storage Temperature Symbol VRM IF(AV) IFSM I2t Tj Tstg Rating 300 60 300 450 −40 to 150 −40 to 150 ec
ELECTRICAL CHARACTERISTICS
