Sanken RD2A
Silicon Diode
| Part No. | RD2A |
|---|---|
| Datasheet | RD2A Download |
| Manufacturer |  Sanken |
| Description | Silicon Diode |
| Buy | Stock & Price |
APPLICATIONS
High Frequency Rectification 3. Flammability UL94V-0(Equivalent) Designs Not Recommended for New ‘041117 SSA-04577 1／7 61426-01 SANKEN ELECTRIC CO., LTD. RD2A 4. Absolute maximum ratings No. Item Symbol Unit Rating Conditions 1 Transient Peak Reverse Voltage VRSM V 600 2 Peak Reverse Voltage VRM V 600 3 Average Forward Current IF(AV) A 1.2 Refer to Derating of 7 4 Peak Surge Forward Current IFSM A 30 10msec. Half sinewave, one shot 5 I2t Limiting Value 6 Junction Temperature 7 Storage Temperature I2t A2s Tj ℃ Tstg ℃ 4.5 -40～+150 -40～+150 Designs 1msec≦t≦10msec 5. Electrical characteristics w No. Item Symbol Unit Ne 1 Forward Voltage Drop VF V or 2 Reverse Leakage Current IR uA ed f 3 Reverse Leakage Current Under High Temperature H･IR uA end 4 Reverse Recovery Time trr1 ns trr2 ns Not Recomm 5 Thermal Resistance Rth(j-l) ℃/W Value 1.55 max. 50 max. 100 max. 50 max. 35 max. 12 max. Conditions IF=1.2A VR=VRM VR=VRM, Tj=150℃ IF=IRP=100mA 90% Recovery point, Tj=25℃ IF=100mA，IRP=200mA 75% Recovery point, Tj=25℃ Between Junction and Lead ‘041117 SSA-04577 2／7 61426-01 SANKEN ELECTRIC CO., LTD.
