Sanken SAE6530P0DA01
The SAE6530P0DA01 is 3-phase motor driver in which output transistors, pre-driver ICs (MICs), bootstrap diodes with current-limiting resistors, and a temperature-sensing thermistor are highly integrated. The IC is suitable for driving 3-phase motor of an automotive high voltage auxiliary equipment system.| Part No. | SAE6530P0DA01 |
|---|---|
| Datasheet | SAE6530P0DA01 Download |
| Manufacturer |  Sanken |
| Description | 650V 30A 3-phase Motor Driver |
| Buy | Stock & Price |
DESCRIPTION
Package DIP29 Pin Pitch: 2.54 mm Mold Dimensions: 60 × 31 × 6.3 mmFEATURES
● AEC-Q100 Qualified● Bare Lead Frame: Pb-free (RoHS Compliant)
● Isolation Voltage: 2500 V (for 1 min)
● Built-in Thermistor
● Built-in Bootstrap Diodes
● CMOS-compatible Input (3.3 V or 5 V)
● Fault Signal Output at Protection Activation DesignsNot to scale
● Shutdown Signal Input
● Adjustable OCP Hold Time w
● Protections Include: e Undervoltage Lockout for Power Supply VBx Pin (UVLO_VBx): Auto-restart N VCCxH Pin (UVLO_VCCxH): Auto-restart r VCCL Pin (UVLO_VCCL): Auto-restart o Overcurrent Protection (OCP): Auto-restart d f Typical Application de Temp. n VCC me INUH com INVH ot Re INWH N INUL U1 VSU 1 VBU 2 SAE6530P0DA01 VCCUH 3 INUH 4 VSV 5 VBV 6 High-side MIC1 VCCVH 7 INVH 8 VSW 9 VBW 10 High-side MIC2 VCCWH 11 INWH 12 INUL 13 High-side MIC3 TH1 VTH 29 TH2 28 Tem p. P 27 CP VP U 26 V 25 M W 24 Controller Specifications
● Output Transistors: IGBT + Freewheeling Diode
● Output Transistor Breakd...
