Sanken TFA107S
the TFA10x s series provides increased isolation voltage (1800 VACRMS), guaranteed for up to 1 minute.| Part No. | TFA107S |
|---|---|
| Datasheet | TFA107S Download |
| Manufacturer |  Sanken |
| Description | Reverse Blocking Triode Thyristor |
| Buy | Stock & Price |
FEATURES AND BENEFITS
DESCRIPTION
● Exceptional reliability This Sanken reverse blocking triode thyristor is designed for● Small fully-molded SIP package with heatsink mounting AC power control, providing reliable, uniform switching for for high thermal dissipation and long life half-cycle AC applications.
● Operating junction temperature to 150°C
● VDRM of 700 or 800 V
● 15.7 ARMS on-state current
● 7 mA typical gate trigger current
● Uniform switching
● UL Recognized Component (File No.: E118037) (suffix I) In comparison with other products on the market, In addition, commutation Design dv/dt is improved. New Package: 3-pin SIP (TO-220F)
APPLICATIONS
● Motor control for small tools● Temperature control, light dimmers, electric blankets
● General use switching mode power supplies (SMPS) Not Recommended for Nottoscale Typical
APPLICATIONS
M Single-phase motor control (for example, electric tool) In-rush current control (for example, SMPS) 28105.04, Rev. 1 TFA10x Series Reverse Blocki...
