B888 Datasheet | SANYO

Features - High DC current gain (5000 or greater). - Large current capacity and wide ASO. - Low saturation voltage : VCE(sat)=- 0.8V typ. Package Dimensions unit:mm 2003A [2SB888] Specifications Absolute Maximum Ratings at Ta = 25˚C Parameter Collector-to-Base Voltage Collector-to-Emitter Voltage Emitter-to-Base Voltage Collector Current Collector Current (Pulse) Allowable Collector Dissipation Junction Temperature Storage Temperature Symbol VCBO VCEO VEBO IC ICP PC Tj Tstg Electrical Characteristics at Ta = 25˚C Conditions Parameter Collector Cutoff Current Emitter Cutoff Current DC Current Gain Gain-Bandwidth Product Output Capacitance Symbol Conditions ICBO IEBO h FE1 h FE2 f T Cob VCB=- 40V, IE=0 VEB=- 8V, IC=0 VCE=- 2V, IC=- 50m A VCE=- 2V, IC=- 500m A VCE=- 5V, IC=- 50m A VCB=- 10V, f=1MHz JEDEC : TO-92 EIAJ : SC-43 SANYO : NP B : Base C : Collector E : Emitter Ratings - 80 - 50 - 10 - 0.7 - 2 600 150 - 55 to +150 Unit V V V A A m W ˚C ˚C Ratings min typ 5000 3000 170 16 max - 0.1 -...
