LA4108 Description
Ordering number:EN4108R Monolithic Linear IC LA4108 5.3W 2-Channel AF Power Amplifier.
LA4108 Key Features
- Low idling current (45mA/2 channels) enabling prolonged battery life
- Less dependence of idling current on VCC
- High power (5.3W typ. x2)
- High ripple rejection (60dB at steady state)
- Low pop noise at the time of power supply ON/OFF and good starting balance between both channels (0.6s.) due to built-in
- Pins provided for pensating high frequency responce
- Low residual noise (0.4mV)
- Wide supply voltage range (6 to 18V) fascilitating design of transformer power supply
- Built-in thermal shutdown circuit
- Designed so that inverse insertion or short between adjacent pins causes no destruction
