LA7680 Description
Ordering number:ENN3343A Monolithic Linear IC LA7680, 7681 Sigle-Chip Signal Processor for Color TV Use Overview Package Dimensions The LA7680 and LA7681 signal processors provide all the ponents required to decode PAL or NTSC Color television signals. On-chip circuits include VIF, SIF, a video processor, a chroma demodulator, and deflection drivers. unit:mm 3149-DIP48S [LA7680, 7681] The self-adjusting signal...
LA7680 Key Features
- Minimized external ponents
- 48-pin shrink DIP
- High-gain VIF amplifier
- Fast-response automatic gain control (AGC)
- No delay between audio input and output
- Muting for both audio and video signals or for audio
- On-chip two-dimensional differential circuit
- Variable current transfer
- 7MHz bandwidth
- PAL and NTSC system patible
