TL431A - 3-terminal adjustable shunt regulator

General Description

The TL431A is a three-terminal adjustable shunt regulator offering excellent temperature stability.

This device has a typical dynamic output impedance of 0.2Ω.

The device can be used as a replacement for zener diodes in many applications.

Key Features

  • The Output Voltage can be Adjusted to 36V Low Dynamic Output Impedance, its Typical Value is 0.2Ω Trapping Current Capability is 1~100mA Low Output Noise Voltage Fast On-State Response The Effective Temperature Compensation in the Working Range of Full Temperature The Typical Value of the Equivalent Temperature Factor in the Whole Temperature Scope is 50 ppm/°C.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
TL431A Adjustable precision shunt regulators nexperia
TL431A 3-terminal programmable shunt regulator ON Semiconductor
TL431A Adjustable Precision Shunt Regulatror Semtron
TL431A Programmable Shunt Regulator Fairchild Semiconductor
TL431A ADJUSTABLE PRECISION SHUNT REGULATOR Diodes

Other Datasheets by SeCoS Halbleitertechnologie GmbH

Part Number Description
TL431BL a three-terminal adjustable shunt regulators
TL432-C Adjustable Accurate Reference Source

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Elektronische Bauelemente TL431A Adjustable Accurate Reference Source RoHS Compliant Product A suffix of “-C” specifies halogen or lead -free DESCRIPTION The TL431A is a three-terminal adjustable shunt regulator offering excellent temperature stability. This device has a typical dynamic output impedance of 0.2Ω. The device can be used as a replacement for zener diodes in many applications. FEATURES The Output Voltage can be Adjusted to 36V Low Dynamic Output Impedance, its Typical Value is 0.
