SA21308A00DED
Description
The SA21308A is a 500m A current linear regulator featuring ultra-low ground current and low dropout voltage.
The device offers an adjustable output voltage with ±1% reference accuracy over temperature, also includes prehensive protection features including over current limiting, short circuit protection, and over-temperature operation.
The SA21308A is available in a pact DFN2×2-6 package.
Applications
- Infotainment Power Supplies
- Automotive Cluster Displays
- Cameras
- Telematics Control Units
- General Purpose Automotive
Features
- Input Voltage Range: 1.62V to 6V
- Adjustable Output Voltage: 0.55V to 5.5V
- Low Dropout Voltage: 110m V (Typ.) at
500m A (3.3V VOUT)
- Power Supply Rejection Ratio (PSRR):
55d B @ 1k Hz
- Output Accuracy: o ±0.85% at 25°C o ±1% from -40°C to 125°C
- Stable with a Minimum of 2.2μF or Larger Ceramic Output Capacitor
- Low Current Consumption: Typical 25μA Quiescent and 0.1μA in Shutdown
- Over Current Limit and Short Circuit Protection
- Over...
