SY21052
Description
The SY21052 develops a high efficiency synchronous step down DC/DC regulator capable of delivering 1.2A continuous, 1.8A peak current. The SY21052 operates over a wide input voltage range from 7V to 85V and integrates a main switch and a synchronous switch with very low RDS(ON) to minimize the conduction loss.
Key Features
- Low RDS(ON) for Internal Switches (Top/Bottom): 500mΩ/240mΩ
- 7-85V Input Voltage Range
- 1.2A Continuous, 1.8A Peak Output Current Capability
- Adjustable Switching Frequency
- Instant PWM Architecture to Achieve Fast Transient Responses
- Programmable Switching Frequency Range: 200~500 kHz
- 2ms Internal Soft-start Limits the Inrush Current
- Precise ±2% 1.2V Reference
- RoHS compliant and Halogen Free
- pact Package: SO8E
