Datasheet Summary
High Efficiency, 500kHz, 3A, 23V Input Synchronous Step Down Regulator
General Description
The SY21143 is a high efficiency 500 kHz synchronous step down DC/DC converter capable of delivering 3A current. The SY21143 operates over a wide input voltage range from 4.5V to 23V and integrates main switch and synchronous switch with very low RDS(ON) to minimize the conduction loss.
Low output voltage ripple and small external inductor and capacitor sizes are achieved with 500 kHz switching frequency. It adopts the instant PWM architecture to achieve fast transient responses for high step down applications
Ordering Information
SY21143- (-
- )- Tempera ture Code Pa cka ge Code Optional...
