SY28480
Description
The SY28480 is a 0.76mΩ ultra-low on-resistance Efuse for using in high current applications such as base stations and servers.
Key Features
- Wide Input Range: 4.5 V to 18 V
- Up to 60 A Peak Current Output, 50 A
- Integrated N-Channel MOSFET with 0.76 mΩ
- Adjustable Slew Rate Control
- Adjustable Current Limit
- Accurate Analog Load Current Monitor
- Adjustable Over Current Alert Output
- Temperature Indicator
- Fault Detection with Status OK Output
- Can be used in Parallel for Higher Current
Applications
- Servers
