SY7302
SY7302 is High Efficiency 1MHz 2A Step Up Regulator manufactured by Silergy.
High Efficiency 1MHz, 2A Step Up Regulator
General Description
SY7302 is a high efficiency, current-mode control Boost DC to DC regulator with an integrated 200mΩ RDS(ON) N-channel MOSFET. The fixed 1MHz switching frequency and internal pensation reduce external ponent count and save the PCB space. The build-in internal soft start circuitry minimizes the inrush current at start-up.
Ordering Information
- (-
- )- Temperature Code Package Code Optional Spec Code
Ordering Number Package type Note
SY7302ABC
SOT23-6
----
Features
- Wide input range: 3-33V bias input, 33Vout max
- 1MHz switching frequency
- Minimum on time: 100ns typical
- Minimum off time: 100ns typical
-...
