SLM2110 Datasheet 600v High And Low Side Driver

Manufacturer: Sillumin

Overview: 600V High and Low Side Driver SLM2110 PRODUCT SUMMARY • VOFFSET • IO+/• VOUT • ton/off (typ.) • Delay Matching (typ.) 600 V max. 1 A / 1.

Datasheet Details

Part number SLM2110
Manufacturer Sillumin
File Size 325.60 KB
Description 600V High and Low Side Driver
Datasheet SLM2110-Sillumin.pdf

General Description

The SLM2110 is a high voltage, high speed power MOSFET and IGBT drivers with independent highand low-side referenced output channels.

Proprietary HVIC and latch immune CMOS technologies enable ruggedized monolithic construction.

The output drivers

Key Features

  • Floating channel designed for bootstrap operation.
  • Fully operational to +600 V.
  • Tolerant to negative transient voltage, dV/dt immune.
  • Gate drive supply range from 10 V to 20 V.
  • Undervoltage lockout for both channels.
  • Logic and power ground +/- 5V offset.
  • Cross-conduction prevention logic.
  • Schmitt-triggered inputs with pull-down.
  • Cycle-by-cycle edge-triggered shutdown logic.
  • Matched propagation delay for bo.
