SPLC562C Datasheet PDF | Sunplus Technology

Sunplus Technology SPLC562C

The SPLC562C is a 240-output segment/common driver IC Common Mode suitable for driving large/medium scale dot matrix LCD panels, and g Built-in 240 bits bi-directional shift register is used in personal computers/work-stations. The (VDD = +2.5V to +5.5V) SPLC562C is good both as a segment driver and a common driver, and it can create a low power consuming, high-resolution LCD.

Part No.	SPLC562C
Datasheet	SPLC562C Download
Manufacturer	Sunplus Technology
Description	240 COM/SEG Driver
Buy	Stock & Price

GENERAL DESCRIPTION

The SPLC562C is a 240-output segment/common driver IC Common Mode suitable for driving large/medium scale dot matrix LCD panels, and g Built-in 240 bits bi-directional shift register is used in personal computers/work-stations. Through the use of (divisible into 120-bits X 2) SST (Super Slim TCP) technology, it is ideal for substantially g Shift clock frequency: 4.0MHz (Max.) decreasing the size of the frame section of the LCD module. ntial nly 2.

FEATURES

Both Segment Mode and Common Mode e O g Number of LCD drive outputs: 240 fid g Supply voltage for LCD drive: +15V to +30V e g Supply voltage for the logic system: +2.5V to +5.5V s g Low power consumption on U g Low output impedance g CMOS silicon gate process (P-type silicon substrate) C R g Package: 278-pin TCP (Tape Carrier Package) & Au bump chip s E Segment Mode lu IN g Shift clock frequency: 1). 20MHz (Max.) (VDD = +5.0V D 10%) p 2). 15MHz (Max.) (VDD = +3.0V to +4.5V) n M 3). 12MHz (Max.) (VDD = +2.5V...
