Sunplus Technology SPLC780D
The SPLC780D, a dot-matrix LCD controller and driver from Character generator ROM: 10880 bits SUNPLUS, is a unique design for displaying alpha-numeric, ─ Character font 5 x 8 dots: 192 characters Japanese-Kana characters and symbols. The SPLC780D ─ Character font 5 x 10 dots: 64 characters provides two types of interfaces to MPU: 4-bit and 8-bit interfaces. By cascading with SPLC100 or SPLC063, the display capability can l be extended.| Part No. | SPLC780D |
|---|---|
| Datasheet | SPLC780D Download |
| Manufacturer |  Sunplus Technology |
| Description | 16COM/40SEG Controller/Driver |
| Buy | Stock & Price |
GENERAL DESCRIPTION
2.FEATURES
The SPLC780D, a dot-matrix LCD controller and driver from● Character generator ROM: 10880 bits SUNPLUS, is a unique design for displaying alpha-numeric, ─ Character font 5 x 8 dots: 192 characters Japanese-Kana characters and symbols.
● Character generator RAM: 512 bits The transferring speed of 8-bit is twice faster than 4-bit. A single ─ Character font 5 x 8 dots: 8 characters SPLC780D is able to display up to two 8-character lines. The CMOS technology ensures the power saves in tia ly the most efficient way and the performance keeps in the highest onfidenUse On rank. ─ Character font 5 x 10 dots: 4 characters
● 4-bit or 8-bit MPU interfaces
● Direct driver for LCD: 16 COMs x 40 SEGs
● Duty factor (selected by program): ─ 1/8 duty: 1 line of 5 x 8 dots ─ 1/11 duty: 1 line of 5 x 10 dots ─ 1/16 duty: 2 lines of 5 x 8 dots / line
● Built-in power on automatic reset circuit
● Built-in oscillator circuit (with external resistor)
● Support external clock operation
● Low Power Consumption
● Package form: 80 QFP or bare chip available s C ER 3.
