TFM201210ALMA
FEATURES
̋By using metal magnetic material with high Saturation magnetic flux density the excellent DC bias characteristics needed for inductors for power circuits can be achieved.
̋With the same product shape and terminal structure as general chip parts it has excellent mounting stability characteristics and can also be mounted to general-purpose land patterns.
̋By using a closed magnetic circuit structure leakage flux is minimized. ̋pliant with AEC-Q200
˙APPLICATION
̋ADAS ECU, in-Vehicle camera (view camera, sensing camera), radar, meter cluster, automotive munication module
˙PART NUMBER CONSTRUCTION
TFM 201210 ALM
Series name
L×W×H dimensions 2.0×1.25×1.0 mm
Characteristic type
Automotive use
R47
Inductance (µH)
Inductance tolerance
Packaging style
Internal code
˙CHARACTERISTICS SPECIFICATION TABLE
LMeasuring DC resistance
Rated current- frequency
Rated voltage Part No.
Isat
Itemp
(μH) Tolerance (MHz)
(mΩ)max.
(mΩ)typ. (A)max.
(A)typ. (A)max....
