Datasheet Summary
General Purpose Relays
Power PCB Relay RT2
SCHRACK
I 2 pole 8 A, 2 CO or 2 NO contacts I DC- or AC-coil I Sensitive coil 400 mW I Reinforced insulation I WG version: Product in accordance to IEC60335-1 I RoHS pliant (Directive 2002/95/EC) as per product date code 0413
Applications
Domestic appliances, heating control, emergency lighting, modems
F0149-B
Approvals
V Z b B REG.-Nr. 6106,
E214025,
14385, C0786
Technical data of approved types on request
Contact data
Contact configuration
2 CO or 2 NO
Contact set single contact
Type of interruption micro disconnection
Rated current
8 A, UL: 10 A
Rated voltage / max.switching voltage AC
250/400 VAC
Limiting continuous...
