PE97640 - Delta-Sigma Modulated Fractional-N Frequency Synthesizer

Description

The PE97640 is a radiation tolerant, high performance, fractional-N PLL capable of frequency synthesis up to 5 GHz.

The device is optimized for commercial space applications and superior phase noise performance.

Features

  • a 5/6 or 10/11 dual modulus prescaler, counters, a delta sigma modulator, a phase comparator and charge pump as shown in Figure 1. Counter values are programmable through either a serial interface or directly hard-wired. The PE97640 is available in a 64-lead CQFP and is manufactured on Peregrine’s UltraCMOS® process, a patented variation of silicon-on-insulator (SOI) technology on a sapphire substrate, offering excellent RF performance and intrinsic radiation tolerance. Figure 1. Functional Diag.

📥 Download Datasheet

Datasheet Details

Part number PE97640
Manufacturer TELEDYNE
File Size 4.62 MB
Description Delta-Sigma Modulated Fractional-N Frequency Synthesizer
Datasheet download datasheet PE97640 Datasheet

📁 Similar Datasheet

  • PE9763 - 3.2 GHz Delta-Sigma modulated Fractional-N Frequency Synthesizer (Peregrine Semiconductor)
  • PE97632 - Fractional-N Frequency Synthesizer (Peregrine Semiconductor)
  • PE97632DIE - Fractional-N Frequency Synthesizer (Peregrine Semiconductor)
  • PE9701 - Integer-N PLL Rad Hard (Peregrine Semiconductor)
  • PE9702 - 3.0 GHz Integer-N PLL (Peregrine Semiconductor)
  • PE9704 - 3.0 GHz Integer-N PLL Radiation Tolerant (Peregrine Semiconductor)
  • PE97240 - Integer-N Frequency Synthesizer (Peregrine Semiconductor)
  • PE90F120 - THYRISTOR MODULE (ETC)
  • PE90F120 - THYRISTOR MODULE (SanRex Corporation)
  • PE90F160 - THYRISTOR MODULE (ETC)
Other Datasheets by TELEDYNE
  • PE9702 - Integer-N PLL Radiation Tolerant
  • PE97240 - Integer-N Frequency Synthesizer
  • PE9304 - Low Power Divide-by-2 Prescaler
  • PE9313 - high-performance static UltraCMOS prescaler
  • PE9354 - SPDT High Power RF Switch
  • PE95421 - SPDT RF Switch
  • PE9601 - Integer-N PLL Radiation Tolerant
  • PE99155 - Hi-Rel 10A DC-DC Converter

Full PDF Text Transcription

Click to expand full text
July 31, 2020 Product Description The PE97640 is a radiation tolerant, high performance, fractional-N PLL capable of frequency synthesis up to 5 GHz. The device is optimized for commercial space applications and superior phase noise performance. The PE97640 features a 5/6 or 10/11 dual modulus prescaler, counters, a delta sigma modulator, a phase comparator and charge pump as shown in Figure 1. Counter values are programmable through either a serial interface or directly hard-wired. The PE97640 is available in a 64-lead CQFP and is manufactured on Peregrine’s UltraCMOS® process, a patented variation of silicon-on-insulator (SOI) technology on a sapphire substrate, offering excellent RF performance and intrinsic radiation tolerance. Figure 1.
