TDLNA002093 - Ultra-Low Noise Amplifier

Description

The TDLNA002093 ultra-low noise amplifier offers industryleading noise figure (NF) and gain performance and can be tuned over a wide range of frequencies from roughly 1.0 to 6.0 GHz.

Features

  • Reference: 5 V / 55 mA / 2.33 GHz.
  • EVB Noise Figure (NF): 0.37 dB.
  • Gain: 22.0 dB.
  • OP1dB: 19.0 dBm.
  • OIP3: 35.5 dBm.
  • Flexible Bias Voltage and Current.
  • Process: GaAs pHEMT.
  • TID: 100 krad (Si).

📥 Download Datasheet

Datasheet Details

Part number TDLNA002093
Manufacturer TELEDYNE
File Size 1.06 MB
Description Ultra-Low Noise Amplifier
Datasheet download datasheet TDLNA002093 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
TDL2 UHF Transparent Data Link transceiver Radiometrix
TDL2A UHF Transparent Data Link transceiver Radiometrix

Other Datasheets by TELEDYNE

Part Number Description
TDLNA002093SEP Ultra-Low Noise Amplifier
TDLNA0430EP GaAs Ultra Low Noise Amplifier
TDLNA2050EP GaAs Ultra Low Noise Amplifier
TDLNA2626SEP 17 - 23 GHz Low Noise Amplifier
TDLNA2628SEP 22 - 31.5 GHz Low Noise Amplifier

Full PDF Text Transcription

Click to expand full text
Features Reference: 5 V / 55 mA / 2.33 GHz • EVB Noise Figure (NF): 0.37 dB • Gain: 22.0 dB • OP1dB: 19.0 dBm • OIP3: 35.5 dBm • Flexible Bias Voltage and Current • Process: GaAs pHEMT • TID: 100 krad (Si) Applications • Satellite Communications • Military and Space Applications • Distributed Antenna Systems • GPS Receivers TDLNA002093 Product Specification Ultra-Low Noise Amplifier Tuning Range: 1.0 to 6.0 GHz Description The TDLNA002093 ultra-low noise amplifier offers industryleading noise figure (NF) and gain performance and can be tuned over a wide range of frequencies from roughly 1.0 to 6.0 GHz.
