TC9402 - VOLTAGE-TO-FREQUENCY/FREQUENCY-TO-VOLTAGE CONVERTERS

General Description

The TC9400/TC9401/TC9402 are low-cost voltage-tofrequency (V/F) converters utilizing low power CMOS technology.

The converters accept a variable analog input signal and generate an output pulse train whose frequency is linearly proportional to the input voltage.

Key Features

  • Voltage-to-Frequency s Choice of Guaranteed Linearity: TC9401 0.01% TC9400 0.05% TC9402 0.25% DC to 100 kHz (F/V) or 1Hz to 100kHz (V/F) Low Power Dissipation 27mW Typ Single/Dual Supply Operation + 8V to + 15V or ± 4V to ± 7.5V Gain Temperature Stability ± 25 ppm/°C Typ Programmable Scale Factor 1.

📥 Download Datasheet

Datasheet Details

Part number TC9402
Manufacturer TelCom Semiconductor
File Size 154.03 KB
Description VOLTAGE-TO-FREQUENCY/FREQUENCY-TO-VOLTAGE CONVERTERS
Datasheet download datasheet TC9402 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
TC9402 Voltage-to-Frequency/Frequency-to-Voltage Converters Microchip Technology
TC9400 Voltage-to-Frequency/Frequency-to-Voltage Converters Microchip Technology
TC9401 Voltage-to-Frequency/Frequency-to-Voltage Converters Microchip Technology
TC9409BF SINGLE CHIP KARAOKE LSI Toshiba
TC9411F CD GRAPHICS DECODER Toshiba

Other Datasheets by TelCom Semiconductor

Part Number Description
TC9400 VOLTAGE-TO-FREQUENCY/FREQUENCY-TO-VOLTAGE CONVERTERS
TC9401 VOLTAGE-TO-FREQUENCY/FREQUENCY-TO-VOLTAGE CONVERTERS
TC9491A LOW POWER/ BANDGAP VOLTAGE REFERENCES
TC9491B LOW POWER/ BANDGAP VOLTAGE REFERENCES
TC901 MONOLITHIC/ AUTO-ZEROED OPERATIONAL AMPLIFIER

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
TC9400 TC9401 TC9402 VOLTAGE-TO-FREQUENCY/FREQUENCY-TO-VOLTAGE CONVERTERS FEATURES Voltage-to-Frequency s Choice of Guaranteed Linearity: TC9401 ......................................................... 0.01% TC9400 ......................................................... 0.05% TC9402 ......................................................... 0.25% DC to 100 kHz (F/V) or 1Hz to 100kHz (V/F) Low Power Dissipation .......................... 27mW Typ Single/Dual Supply Operation ................................. + 8V to + 15V or ± 4V to ± 7.5V Gain Temperature Stability .......... ± 25 ppm/°C Typ Programmable Scale Factor 1 GENERAL DESCRIPTION The TC9400/TC9401/TC9402 are low-cost voltage-tofrequency (V/F) converters utilizing low power CMOS technology.
