TOREX SEMICONDUCTOR XC6383
The XC6383 series is a group of PFM controlled step-up DC/DC converters. The XC6383 series employs CMOS process and laser trimming technologies so as to attain low power and high accuracy. Unlike conventional PFMs, the XC6383 automatically switches duty ratio (55% / 75%) when it senses changes in load and can support both large and small currents.| Part No. | XC6383 |
|---|---|
| Datasheet | XC6383 Download |
| Manufacturer |  TOREX SEMICONDUCTOR |
| Description | PFM Controlled, Step-Up DC/DC Converter |
| Buy | Stock & Price |
FEATURES
● Automatic duty ratio switch.● Low ripple and highly efficient from low current to high current.
● Automatic duty ratio switch.
● Adding an external transistor can improve the output capability by up to several hundred mA.
● Stand-by (CE) function added version to the XC6383A.
● Stand-by current: 0.5µA max.
● Stand-by (CE) function added version to the XC6383B.
● Stand-by current: 0.5µA max. Built-in Transistor Separated
● Independent power supply and set-up voltage "Lx" lead "VDD" and "VOUT" leads sensing leads allow designing of PFM controllers. 4 XC6383F Switchable SOT-25, SOT-89-5 External Transistor Separated
● Independent power supply and set-up voltage "EXT" lead "VDD" and "VOUT" leads sensing leads allow designing of PFM controllers. GOrdering Information XC6383qwerty XC6383 series A B q C D E F w e r 1 M t P R y L PFM Controlled 2 Step 3-pin. Built-in switching transistor 3-pin. External switching transistor Stand-by capability. (5-pin) Built-in switching transistor...
