TOREX SEMICONDUCTOR XC6412
The XC6411P/XC6412B series is a dual LDO regulator manufactured using CMOS process. The series achieves very low supply current 0.8μA typical by channel and consists of a reference voltage source, an error amplifier, a current foldback circuit, and a phase compensation circuit plus a driver transistor. The XC6411P series in SOT-25 packages, the XC6412B series in SOT-26 packages make high density mounting possible.| Part No. | XC6412 |
|---|---|
| Datasheet | XC6412 Download |
| Manufacturer |  TOREX SEMICONDUCTOR |
| Description | Low Power Consumption Dual Voltage Regulator |
| Buy | Stock & Price |
GENERAL DESCRIPTION
Therefore, the series is ideally suited for applications where high density mounting is required such as mobile equipment. Each output voltage of two regulators VR1 and VR2 is selectable in 0.1V increments within a range of 0.9V to 5.0V by laser trimming. The series is compatible with low ESR ceramic capacitors, which provides stable outputs. The VR1 and VR2 are completely isolated so that a cross talk during load fluctuation is minimized. The current limiter's foldback circuit also operates as a short protection for the output pin.●
APPLICATIONS
●Digital audio equipment●Smart phones / Mobile phones
●Portable games
●Digital sill cameras / Camcorders
●Mobile devices / terminals
●
FEATURES
Maximum Output Current : 200mA (300mA Limit TYP.) @ VOUT=3.0V, VIN=4.0V Dropout Voltage : 320mV @ IOUT = 100mA @ VOUT = 3.0V Input Voltage Range : 1.5V ~ 6.0V Output Voltage Range Highly Accurate Low Power Consumption : 0.9V ~ 5.0V (0.1V increments) :±2% (1.5V＜VOUT≦5.0V) ±0.03V (0.9...
