2SA1384 datasheet by Toshiba.
| Part number | 2SA1384 |
|---|---|
| Datasheet | 2SA1384_ToshibaSemiconductor.pdf |
| File Size | 181.98 KB |
| Manufacturer | Toshiba |
| Description | Silicon PNP Triple Diffused Type Transistor |
|
|
TOSHIBA Transistor Silicon PNP Triple Diffused Type (PCT process) 2SA1384 2SA1384 High Voltage Control Applications Plasma Display, Nixie Tube Driver Applications Cathode Ray Tube Brightness Control Applications Unit: VCBO = −300 V, VCEO = −300 V Low saturation voltage: VCE (sat) = −0.5 V (max) Small collector output capacitance:.
| Brand Logo | Part Number | Description | Other Manufacturers |
|---|---|---|---|
 |
2SA1384 | PNP Transistors | Kexin |
