HT7520-2 Description
The UMW HT75xx-2 is a low-dropout linear voltage regulator using CMOS technology. It has a 45V voltage rating and offers several fixed output voltages ranging from 2.0V to 5.0V, capable of outputting 250mA of current.
- Part: HT7520-2
- Manufacturer: UMW
- Size: 1.73 MB
