UET14A05L03-BK
Features
UET14A05L03 is surge rated diode arrays designed to protect high speed data interfaces. It has been specifically designed to protect sensitive ponents which is connected to data and transmission lines from overvoltage caused by electrostatic discharge (ESD), electrical fast transients (EFT), and lightning.
3.Applications
IEC61000-4-2 ESD 15KV Air, 8KV contact pliance SOT-143 surface mount package Protects two high-speed data lines and one power line Array of surge rated, low capacitance diodes
4.Pinning information
2.Applications
USB power and data line protection Ethernet 10Base T Video line protection I2C bus protection WAN/LAN equipment ISDN S/T interface Microcontroller input protection Portable electronics
Working voltage: 5V Low leakage current Low clamping voltage Lead Free/Ro HS pliant Solder reflow temperature: Pure Tin-Sn, 260~270
SOT-143
UTD Semiconductor Co.,Limited .umw-ic.
Feb.2025
1 of 6
.umw-ic.
UMW UET14A05L03-BK
5.Absolute Maximum...
