TL082 - GENERAL PURPOSE DUAL J-FET OPERATION AMPLIFIER

General Description

The UTC TL082 is a high speed J-FET input dual operational amplifier.

It incorporates well matched, high voltage J-FET and bipolar transistors in a monolithic integrated circuit.

Key Features

  • S.
  • Low input bias and offset current.
  • Wide common-mode (up to VCC+ ) and differential voltage range.
  • Output short-circuit protection.
  • High input impedance J-FET input stage.
  • Internal frequency compensation.
  • Latch up free operation.
  • High slewrate:10V/µs (typ. ).

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
TL082 Wide Bandwidth Dual JFET Input Operational Amplifier National Semiconductor
TL082 General purpose JFET dual operation amplifiers STMicroelectronics
TL082 GENERAL PURPOSE JFET INPUT OPERATIONAL AMPLIFIERS Diodes
TL082 JFET-Input Operational Amplifiers Texas Instruments
TL082-N Wide Bandwidth Dual JFET Input Operational Amplifier Texas Instruments

Other Datasheets by Unisonic Technologies

Part Number Description
TL084 LOW NOISE QUAD J-FET OPERATIONAL AMPLIFIER
TL062 LOW POWER DUAL J-FET OPERATIONAL AMPLIFIER
TL071 LOW NOISE DUAL J-FET OPERATIONAL AMPLIFIER
TL072 LOW NOISE DUAL J-FET OPERATIONAL AMPLIFIER
TL074 LOW NOISE QUAD J-FET OPERATIONAL AMPLIFIER

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
UNISONIC TECHNOLOGIES CO., LTD TL082 LINEAR INTEGRATED CIRCUIT GENERAL PURPOSE DUAL J-FET OPERATIONAL AMPLIFIER  DESCRIPTION The UTC TL082 is a high speed J-FET input dual operational amplifier. It incorporates well matched, high voltage J-FET and bipolar transistors in a monolithic integrated circuit. The device features high slew rates, low input bias and offset current, and low offset voltage temperature coefficient.  FEATURES * Low input bias and offset current * Wide common-mode (up to VCC+ ) and differential voltage range * Output short-circuit protection * High input impedance J-FET input stage * Internal frequency compensation * Latch up free operation * High slewrate:10V/µs (typ.
