LM556 - DUAL TIMER

General Description

The UTC LM556 dual monolithic circuit is a highly stable controller capable of producing accurate delays or oscillation.

The UTC LM556 is the dual of UTC NE555; timing is provided an external resistor and capacitor for each function.

Key Features

  • S.
  • High Current Driver Capability(=200mA).
  • Adjustable Duty Cycle.
  • Timing From μSec to Hours.
  • Temperature Stability of 0.005%/C.
  • TTL Compatible.
  • Operates in Both Astable and Monostable Modes.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
LM556 Dual Timer National Semiconductor
LM556 Dual Timer Fairchild Semiconductor
LM556 Dual Timer Texas Instruments
LM55107A dual line receivers National Semiconductor
LM55108A dual line receivers National Semiconductor

Other Datasheets by Unisonic Technologies

Part Number Description

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
UNISONIC TECHNOLOGIES CO., LTD LM556 LINEAR INTEGRATED CIRCUIT DUAL TIMER  DESCRIPTION The UTC LM556 dual monolithic circuit is a highly stable controller capable of producing accurate delays or oscillation. The UTC LM556 is the dual of UTC NE555; timing is provided an external resistor and capacitor for each function. The two timers operate independently of each other, sharing only VCC and GND. The circuits may be triggered and reset on falling wave forms. The output structures may sink or source 200mA.  FEATURES *High Current Driver Capability(=200mA) *Adjustable Duty Cycle *Timing From μSec to Hours *Temperature Stability of 0.
