AO4476A
AO4476A is 30V N-Channel MOSFET manufactured by VBsemi.
FEATURES
- Halogen-free
- Trench Power MOSFET
- Optimized for High-Side Synchronous
Rectifier Operation
- 100 % Rg Tested
- 100 % UIS Tested
S1 S2 S3 G4
SO-8
8D 7D 6D 5D
APPLICATIONS
- Notebook CPU Core
- High-Side Switch
Top View
S N-Channel MOSFET
ABSOLUTE MAXIMUM RATINGS TA = 25 °C, unless otherwise noted
Parameter
Symbol
Limit
Unit
Drain-Source Voltage Gate-Source Voltage
± 20
TC = 25 °C
Continuous Drain Current (TJ = 150 °C)
TC = 70 °C TA = 25 °C
10 9b, c
Pulsed Drain Current
TA = 70 °C IDM
7b, c 45
Continuous Source-Drain Diode Current
TC = 25 °C TA = 25 °C
3.7 2.0b,...
