AO4862 - 30V Dual N-Channel MOSFET

VBsemi

Key Features

Halogen-free According to IEC 61249-2-21 Definition.
Trench Power MOSFET.
100 % UIS Tested.
100 % Rg Tested.
Compliant to RoHS Directive 2002/95/EC.

AO4862 30v dual n-channel mosfet by VBsemi - Datasheet Preview

Datasheet Details

Part number	AO4862
Manufacturer	VBsemi
File Size	216.84 KB
Description	30V Dual N-Channel MOSFET
Datasheet	AO4862 Datasheet

📁 Similar Datasheet

Part Number	Description	Manufacturer
AO4862	Dual N-Channel MOSFET	Kexin
AO4862	30V Dual N-Channel AlphaMOS	Alpha & Omega Semiconductors
AO4800	30V Dual N-Channel MOSFET	Alpha & Omega Semiconductors
AO4800B	30V Dual N-Channel MOSFET	Alpha & Omega Semiconductors
AO4800BL	Dual N-Channel MOSFET	Alpha & Omega Semiconductors

Other Datasheets by VBsemi

Part Number	Description
AO4800	Dual N-Channel 30V MOSFET
AO4801	Dual P-Channel 30V MOSFET
AO4805	Dual P-Channel MOSFET
AO4812	Dual N-Channel 30V MOSFET
AO4813	Dual P-Channel MOSFET

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text

AO4862-VB AO4862-VB Datasheet Dual N-Channel 30-V (D-S) MOSFET www.VBsemi.com PRODUCT SUMMARY VDS (V) RDS(on) (Ω) 0.022 at VGS = 10 V 30 0.026 at VGS = 4.5 V ID (A) 6.8 6.0 Qg (Typ.) 15 nC SO-8 S1 1 G1 2 S2 3 G2 4 8 D1 7 D1 6 D2 5 D2 Top View FEATURES • Halogen-free According to IEC 61249-2-21 Definition • Trench Power MOSFET • 100 % UIS Tested • 100 % Rg Tested • Compliant to RoHS Directive 2002/95/EC APPLICATIONS • Set Top Box • Low Current DC/DC D1 D2 G1 S1 N-Channel MOSFET G2 S2 N-Channel MOSFET ABSOLUTE MAXIMUM RATINGS TA = 25 °C, unless otherwise noted Parameter Symbol Limit Unit Drain-Source Voltage Gate-Source Voltage VDS 30 V VGS ± 20 TC = 25 °C 6.8a Continuous Drain Current (TJ = 150 °C) TC = 70 °C TA = 25 °C ID 5.6 6.
