BAV20WS - Small Signal Switching Diodes

Download the BAV20WS datasheet PDF. This datasheet also covers the BAV19WS variant, as both devices belong to the same small signal switching diodes family and are provided as variant models within a single manufacturer datasheet.

Key Features

  • Silicon epitaxial planar diodes.
  • For general purpose.
  • AEC-Q101 qualified available.
  • Base P/N-E3 - RoHS-compliant, commercial grade.
  • Base P/N-HE3 - RoHS-compliant, AEC-Q101 qualified.
  • Material categorization: for definitions of compliance please see www. vishay. com/doc?99912 PARTS TABLE PART TYPE.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (BAV19WS-Vishay.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number BAV20WS
Manufacturer Vishay
File Size 85.03 KB
Description Small Signal Switching Diodes
