Datasheet Summary
W25X10L, W25X20L, W25X40L, W25X80L
1M-BIT, 2M-BIT, 4M-BIT AND 8M-BIT 2.5V SERIAL FLASH MEMORY WITH 4KB SECTORS AND DUAL OUTPUT SPI
Publication Release Date: February 27, 2008
-1-
Revision I
W25X10L, W25X20L, W25X40L, W25X80L
1. GENERAL DESCRIPTION
The W25X10L (1M-bit), W25X20L (2M-bit), W25X40L (4M-bit) and W25X80L (8M-bit) Serial Flash memories provide a storage solution for systems with limited space, pins and power. The 25X series offers flexibility and performance well beyond ordinary Serial Flash devices. They are ideal for code download applications as well as storing voice, text and data. The devices operate on a single 2.5V ( a range of 2.3V to 3.3V) power supply with current...
