GENERAL DESCRIPTION
With W83310DS/DG design, a high integration, high performance, and cost-effective solution is promoted. 2. FEATURES
Regulates a bi-directional power with driving and sinking capability Provides achieve continuous 2.0Amp driving and sinking current Power MOSFET integrated Low external component count Low output voltage offset VCNTL Operates with +3.3V & 2.5 V power 8-SOP 150mil small power package Low cost and easy to use 3. APPLICATIONS
DDR/DDRII Bus Termination Regulator Active Termination Bus Intel® Springdale GMCH-VTT Support SSTL-2 SSTL-3 All Trademark and Brand name belong to their respective owners. 1 Publication Release Date: 2005/May Revision 0.9 W83310DS/DG 4. Pin Configuration and DESCRIPTION
- W83310DS/DG VIN 1 GND 2 VREF1 3 VOUT 4 W83310DS/DG PRELIMINARY 8 VREF2 7 ENABLE 6 VCNTL 5 BOOT_SEL SYMBOL VIN GND VREF1 VOUT BOOT_SEL VCNTL ENABLE VREF2 PIN FUNCTION 1 Main power input pin. 2 Power ground. Internal reference voltage source 1. 3 Reference voltage on the pin will be referred with the value of pin BOOT_SEL set high.
