Winbond Electronics Corporation W83877ATF
The W83877ATF is an enhanced version from Winbond's most popular I/O chip W83877F which integrates the disk drive adapter, serial port (UART), IrDA 1.0 SIR, parallel port, configurable plugand-play registers for the whole chip plus additional powerful features: IrDA 1.1 (MIR for 1.152M bps or FIR for 4M bps), TV remote IR, ACPI, serial IRQ, full 16-bit address decoding, and ACPI compliant. The disk drive adapter functions of W83877ATF include a floppy disk drive controller compatible with the industry standard 82077/765, data separator, write pre-compensation circuit, decode logic, data rate selection, clock generator, drive interface control logic, and interrupt and DMA logic. The wide range of functions integrated onto the W83877ATF greatly reduces the number of components required for interfacing with floppy disk drives.W83877ATF Specifications
- Package : QFP
- Min Voltage : 4.5V
- Max Voltage : 5.5V
- Interface : PCI
- I/Os : 10
- Terminals : 100
- Max Operating Temp : 70°C
- Min Operating Temp : 0°C
Source:
Octopart
| Part No. | W83877ATF |
|---|---|
| Datasheet | W83877ATF Download |
| Manufacturer |  Winbond Electronics Corporation |
| Description | WINBOND I/O |
