WEO009616B
Key Features
- Pin for charge pump capacitor; Connect to each other with a 2 C2P capacitor. 3 C1P C2P/C2N
- Pin for charge pump capacitor; Connect to each other with a 4 C1N capacitor. This is the power supply pin for the internal buffer of the DC/DC voltage 5 VBAT converter. It must be connected to external source when the converter is used. It should be connected to VDD when the converter is not used. 6 NC No connection 7 VSS This is a ground pin. 8 VDD Power supply pin for core logic operation. This pin is reset signal input. When the pin is low, initialization of the chip is 9 RES# executed. Keep this pin HIGH (i.e. connect to VDD) during normal operation
