WINSTAR Display WEO128128G
OLED
| Part No. | WEO128128G |
|---|---|
| Datasheet | WEO128128G Download |
| Manufacturer | WINSTAR Display |
| Description | OLED |
| Buy | Stock & Price |
ABSOLUTE MAXIMUM RATINGS
Parameter Symbol Min Max Unit Supply Voltage for Logic VDD -0.3 3.6 V Supply Voltage for Display VPP -0.3 17.0 V Operating Temperature TOP -40 +80 °C Storage Temperature TSTG -40 +85 °CELECTRICAL CHARACTERISTICS
DCELECTRICAL CHARACTERISTICS
Item Symbol Condition Min Typ Max Unit Supply Voltage for Logic Supply Voltage for Display VDD VPP － 1.65 3.0 3.3 V － 7.0 12.0 12.5 V Input High Volt. Input Low Volt. VIH － 0.8×VDD － VDD V VIL － 0 － 0.2×VDD V Output High Volt. Output Low Volt. 50% Checkerboard operating Current VOH VOL IPP － 0.8×VDD － VDD V － 0 － 0.2×VDD V VPP=12V － 15.0 25.0 mA WEO128128G 第 5 頁，共 5 頁
