WF28GTLAJDNN0 Datasheet | WINSTAR Display

Winstar Display Co., LTD 華凌光電股份有限公司 WEB: https://.winstar..tw E-mail: sales@winstar..tw SPECIFICATION MODULE NO.: WF28GTLAJDNN0# General Specifications Item Dimension Unit Size 2.8 inch Dot Matrix 240 x RGB x 320(TFT) dots Module dimension 50.0(W) x 69.2(H) x 2.3(D) mm Active area 43.2 x 57.6 mm Dot pitch 0.18 x 0.18 mm LCD type TFT, Normally White, Transmissive View Direction 6 o’clock Gray Scale Inversion Direction 12 o’clock Interface Aspect Ratio Portrait Backlight Type LED, Normally...
