YAMAHKi. s I
2-Channel Serial Input Floating D/ A Converter (DAC-MS)
- OUTLINE YM3012: DAC-MS (hereinafter referred to as D AC) is a floating D /A converter with serial input for two channels . It can generate analog output (dynamic range 16 bits) of l 0-bit mantissa section and 3-bit exponent section on the basis of input digital signal.
- Features
- An external buffer operational amplifier is provided to obtain ana log output easily.
- A wide dynamic range with 16 bits.
- patible with PCM audio sources of up to 2 channels
- Built-in sample hold ana log switches
- It is possible to obtain low noise, low harmonic distortion and good temperature characteristics.
- Monolithic chip...
