RB500V-40
RB500V-40 is Schottky Barrier Rectifier manufactured by Yangjie Electronic.
RB500V-40 Schottky Barrier Rectifier
RoHS
PLIANT
Features
- Moisture sensitivity level 1
- Reverse voltage：40V
- Average forward current ：100mA
Application
- High frequency and low voltage rectifier
Mechanical data
- Package： SOD-323
- Terminals：Tin plated leads, solderable per J-STD-002 and JESD22-B102
- Maximum Ratings (Ta=25℃ Unless otherwise specified)
Parameter Device marking code Repetitive peak reverse voltage Forward current Non-repetitive surge peak forward current @ t=8.3ms half-sine wave Non-repetitive surge peak forward current @ t=1ms square wave Power dissipation Junction temperature Storage temperature
Symbol
VRRM IF IFSM PD TJ
TSTG
Unit
V mA A mW ℃ ℃
Value
45...
